Brief introduction
Applied for fine and medium grain solid particle suspension separation, the solid particle could be granule, crystal or fiber type. Especially for the separation which the material has high viscosity, fine grain, poisonous and inflammable. Widely used in the area of chemical, pharmaceutical, food, light industry, environment protection etc.
Technical parameters
| Model/Item | Basket volume(L) | Loading Capacity(kg) | Max. Speed(r/min) | Motor power (Kw) | Size (including shock absorb) (mm) |
| PPSBD60S | 45 | 60 | 1800 | 5.5 | 1700*1200*1700 |
| PPSBD135S | 100 | 135 | 1500 | 7.5 | 1700*1400*1960 |
| PPSBD180S | 140 | 180 | 1080 | 15 | 1968*1500*2060 |
| PPSBD250S | 190 | 250 | 1200 | 15 | 1968*1200*2400 |
| PPSBD320S | 260 | 320 | 970 | 18.5 | 2280*1800*2350 |
Features
1. The full-closed structure can be used in those toxic, inflammable or explosive site.
2. The machine is PLC controlled, with the variable-frequency speed regulator and the braking resistance and the
hydraulic or pneumatic device, the machine can be automatically or manually operated.
3. Processes of start, the feeding, the de-watering, the washing and the discharging are all completed automatically. The
machine can be thoroughly cleaned, and it’s safe and reliable, which meets the GMP standard.
4. The hydraulic scraping system is made of stainless steel, is driven by the closed hydraulic ram, and can be contacted
with the liquid directly.
Applications
Apply to separating the suspension containing particles, but also fibers, especially the highly sticky, containing micro particles, poisonous and flammable materials, like antibiotics, vitamins, and minerals, salts, gourmet powders, foodstuff additives, amylum, sugar, chemical flavors, thiamin, plasters, Glauber's salt, bluestone, potassium chloride, borax, dyestuffs, pigment, resin, pesticides, and environmental protection. The centrifuge is highly automated, has large capacity and can be remote-controlled.
Our services
1. 12 months guarantee period from machine arriving date.
2. Our technicians could be dispatched for overseas service.
3. 7*24 hours technical consultation.
4. Your workers could get trained both in our factory and yours.
5. Routine tracing till the machine work properly will be done timely.
6. Your suggestions or any comments & reflection would be treated in priority.
7. Marketing team will visit you during our visit in your country if you require.
Tips:Scraper Bottom Discharge Centrifuge,discharging centrifuge,flat bottom centrifuge
